Most aircon remotes are covered in small icons that made perfect sense when the manual was sitting on the bench. A few years later, the manual is gone and half those symbols are a mystery. This article focuses specifically on cooling symbols, the icons Australians use every day but rarely fully understand. Knowing what each one does helps you cool your home more efficiently and avoid accidentally running the wrong mode all afternoon.
We'll walk through the core cooling modes (cool, fan and auto), explain the dry mode snowdrop icon that often gets confused with cool mode, cover temperature and fan speed controls, and flag a handful of lesser-known symbols that appear on popular brands like Daikin, Mitsubishi Electric, Fujitsu and Panasonic. By the end, your remote will make a lot more sense.
Key takeaways
Three symbols appear on virtually every aircon remote sold in Australia, regardless of brand or price point. These are cool mode, fan mode and auto mode. Understanding what each one actually does will help you pick the right setting for the conditions outside, rather than just defaulting to the same mode every time.
The snowflake icon is the primary cooling symbol on any split system remote. Selecting it activates the refrigeration cycle, meaning the compressor runs, refrigerant circulates through the system, and the unit actively removes heat from the room to bring the temperature down to your set point. This is the mode most Australians use on hot summer days.
For most homes, a set temperature of 24 to 26°C strikes the right balance between comfort and running costs. Setting it lower than 22°C rarely makes the room cool faster. It just keeps the compressor running longer once the room reaches temperature. Cool mode is the workhorse of any split system and the symbol you'll use most from November through to March.
One thing worth knowing: cool mode will not operate if the outdoor temperature drops below the unit's minimum operating threshold, which varies by model. On very cold nights, the system may simply stop cooling or switch off automatically.
The fan icon (usually a stylised propeller or spinning blade) tells the unit to run the indoor fan only. No compressor, no refrigerant cycle, no active cooling. The unit simply circulates the air already in the room.
This mode is genuinely useful on mild days when the room feels stuffy but not hot, or when you've already cooled the space down and just want to keep the air moving. Because the compressor isn't running, fan mode uses a fraction of the electricity that cool mode does. It won't lower the room temperature, but it can make 26°C feel noticeably more comfortable through air movement alone.
Auto mode is often shown as the letter 'A', or as a combined sun-and-snowflake icon depending on the brand. In this mode, the unit reads the current room temperature, compares it to your set temperature, and decides whether to heat or cool automatically. You set the target temperature and the system does the rest.
This is particularly handy during spring and autumn in Australian cities, where mornings can be cool and afternoons warm. Rather than manually switching between heat and cool throughout the day, auto mode handles the transition for you. Daikin, Mitsubishi Electric, Fujitsu and Panasonic all include auto mode on their split systems, though the exact icon design varies slightly between brands and remote generations.
For a deeper look at all operating modes including heat and dry, see our guide to air conditioner modes explained.
Fan speed and airflow direction symbols control how your air conditioner moves cooled air around the room. Fan speed icons (usually bars, numbers or text labels) set how hard the indoor fan works, while airflow direction symbols control where that air is pointed. Getting these two settings right makes a noticeable difference to comfort, noise levels and how quickly a room reaches your target temperature.
Fan speed is typically shown as one, two or three bars, the numbers 1 to 3, or text labels reading 'Low', 'Med' and 'High'. Some remotes add a fourth 'Turbo' or 'Powerful' setting for maximum airflow. Each level suits a different situation.
Some brands include a dedicated 'Quiet' or 'Silent' mode, shown as a crescent moon or the letter 'Q'. This drops the fan below its standard low setting for near-silent overnight operation. Daikin and Mitsubishi Electric both include this on several of their remote models. These controls are standard across most split system air conditioning units we install.
The swing or louvre symbol controls where the indoor unit directs its airflow. On most Daikin and Mitsubishi Electric remotes, this appears as a small louvre icon with an arc beneath it, indicating the louvre will move automatically. Pressing it once typically activates auto-swing, where the louvre sweeps up and down continuously to distribute cooled air evenly across the room.
A useful tip: if your remote lets you fix the louvre at a set angle rather than swinging, point it slightly upward in cool mode. Cold air is denser than warm air and naturally falls, so angling the airflow upward lets it descend gradually across the whole room rather than blasting straight at floor level. This improves even distribution and can make the room feel more comfortable at a slightly higher set temperature.
Some units also include a horizontal swing symbol, shown as left-right arrows or a top-down louvre icon. This moves the airflow side to side and is particularly useful in open-plan spaces where you want coverage across a wider area. Not all remotes include horizontal swing control, as some units handle it automatically or fix the horizontal louvre position at the factory.
Beyond the main cooling controls, most aircon remotes include several secondary symbols that relate to comfort, energy use and scheduling. Dry mode, sleep mode, the timer and economy mode each serve a specific purpose, and once you understand what they do, you'll find yourself reaching for them far more often than you might expect.
The water droplet icon activates dry mode, which prioritises dehumidification over temperature reduction. In dry mode, the unit runs the compressor at a low, steady rate to condense moisture from the air without aggressively dropping the room temperature. The result is air that feels less clammy and more comfortable, even if the thermometer reading barely changes.
This mode is particularly useful in humid coastal Australian climates, including Sydney, the Central Coast and parts of Melbourne during summer. On days where the air feels thick and sticky but the temperature isn't extreme, dry mode often delivers more comfort than cool mode at a lower running cost. It still cools the room slightly as a byproduct of the dehumidification process, but that's not its primary function. For a full breakdown of what dry mode does and when to use it, we have a dedicated guide.
The crescent moon icon activates sleep mode. Rather than holding the room at a fixed temperature all night, sleep mode gradually raises the set temperature by around 0.5 to 1°C per hour over the first few hours. This prevents the unit from overcooling the room in the early hours of the morning when outdoor temperatures drop, which saves energy and stops you waking up cold under a thin sheet in July.
The clock icon opens the timer function, which lets you schedule when the unit turns on or off. A practical use case: set the timer to start cooling 30 minutes before you get home from work, so the room is already at a comfortable temperature when you walk in. This avoids the temptation to crank the unit to its lowest setting the moment you arrive, which is harder on the system and costs more to run.
Economy mode is shown as 'ECO', 'Econo' or a leaf icon depending on the brand. It works by capping the compressor's maximum output, which reduces peak electricity draw at the cost of slightly slower cooling. The room will still reach your set temperature, it just takes a little longer to get there.
The Daikin Cora series, including the FTXM25Y that we regularly install, includes a dedicated 'Econo' mode symbol on its remote alongside the 'Powerful' mode icon. The Mitsubishi Electric MSZ-AP series remote features a Weekly Timer icon and the 3D i-see Sensor indicator, which adjusts airflow based on where people are detected in the room. The Fujitsu ASTG series includes a physical Economy button on the remote as well as a Coil Dry symbol, which runs the fan briefly after shutdown to dry the indoor coil and reduce mould growth.
If any of these modes stop responding correctly on your remote, it may be time to book an air conditioning service to check the unit.
Most cooling symbols are universal across brands, but each manufacturer adds a handful of proprietary icons for their own features. Daikin, Mitsubishi Electric, Fujitsu and Panasonic all have at least two or three brand-specific symbols that won't appear in a generic remote guide. Knowing what these icons do saves you from accidentally leaving a unit in a mode you didn't intend.
Daikin remotes include three icons that often catch people off guard. The 'Econo' symbol (usually the word 'ECONO' or a leaf-style icon) caps the unit's power draw, which is handy if you're running multiple appliances at once and want to avoid tripping a circuit. The 'Powerful' mode icon, shown as a lightning bolt or the letter 'P', does the opposite. It pushes the system to maximum output for a rapid cool-down, typically for around 20 minutes before returning to normal operation. The 'Comfort Airflow' symbol redirects airflow upward in cool mode to avoid blowing cold air directly at occupants.
These three icons appear on the Daikin Cora series, including the FTXM25Y that we regularly install in Sydney homes. For a full breakdown of every icon on a Daikin remote, see our Daikin remote symbols explained guide.
Mitsubishi Electric remotes include a few icons tied to their sensor and air quality technology. The '3D i-see Sensor' indicator light or icon shows when the unit's infrared sensor is actively detecting occupants and adjusting airflow direction toward or away from them, depending on your preference setting. The 'Weekly Timer' icon (a small calendar or clock symbol) indicates the unit has a programmed weekly schedule active, which is easy to accidentally leave on after setting it once. The 'Plasma Quad' symbol, a small filter or spark icon, shows when the air purification function is running. These features are standard on the Mitsubishi Electric MSZ-AP series.
Fujitsu remotes have a physical 'Economy' button rather than a symbol-only control, though the active state is shown on the display. The 'Minimum Heat' symbol, a small flame with a downward arrow, keeps the room from dropping below a set floor temperature in winter without running a full heating cycle. The 'Coil Dry' icon, often a coil with a fan symbol, runs the indoor fan for a short period after the unit shuts off to dry the evaporator coil and reduce the chance of mould growth inside the unit. This last feature is particularly worth knowing about on the Fujitsu ASTG series, as it can look like the unit is still running when it's actually just completing its shutdown routine.
Panasonic remotes feature two proprietary icons worth knowing. The 'nanoe X' symbol, a small stylised molecule or droplet icon, indicates the air purification and deodorising function is active. 'ECONAVI' is shown as a small sensor or leaf icon and represents Panasonic's occupancy and sunlight detection system, which adjusts output based on activity in the room. Both are comfort and efficiency features rather than core cooling controls, so they won't affect whether the unit cools, just how efficiently it does so.
If you spot a symbol on your remote that isn't covered here, the brand's support website will have a downloadable PDF manual for your specific model. Alternatively, a quick call to a technician who works with that brand regularly will get you an answer in under a minute.
The snowflake symbol activates cool mode, which runs the full refrigeration cycle to actively lower the room temperature. The compressor starts, refrigerant circulates through the system, and heat is removed from the indoor air and expelled outside. This is the primary cooling mode used on hot days and the most energy-intensive setting on the remote.
Cool mode prioritises lowering the room temperature by running the compressor at full capacity. Dry mode prioritises removing humidity from the air by running the compressor at a lower, steadier rate, which reduces clamminess without aggressively dropping the temperature. On humid but mild days, dry mode often delivers more comfort than cool mode and uses less electricity to do it.
The auto symbol, shown as the letter 'A' or a combined sun-and-snowflake icon, lets the unit decide whether to heat or cool based on the difference between the current room temperature and your set temperature. You choose the target temperature and the system switches between heating and cooling automatically. It's most useful during spring and autumn when temperatures shift significantly between morning and afternoon.
Most unrecognised symbols are brand-specific features like air purification modes, sensor indicators or energy-saving functions. They won't affect basic cooling operation if left in their default state. Check the brand's website for a downloadable manual for your specific model number, or contact a technician who services that brand regularly for a quick explanation.
Most aircon remotes share the same core cooling symbols, and understanding them puts you in control of your comfort and your running costs. Once you know what the snowflake, water droplet, fan and auto icons actually do, you can stop guessing and start getting real performance from your system.
That said, some remotes, particularly older models or less common brands, can still leave you scratching your head. If your unit isn't responding the way you'd expect, or you're thinking about upgrading to a newer system with a more intuitive controller, our team is happy to help.
